Features:
1.1 Completely waterproof design for many conditions.（Note: please dry and clean it after usage for avoiding rusty connectors.）
1.2 integrated switch-mode BEC with constant current of 4A
1.3 Tunable drag brake and drag brake rate for different automobiles,trakes and control feel.
1.4 Adjustable PWM frequency coupled with advanced freewheeling (/DEO) technology guarantees great throttle linearity and driving feel.
1.5 9 degrees of acceleration/punch from soft to aggressive for various vehicles ，tires and tracks.
1.6 several protections ：low-voltage cutoff protection ，thermal protection，and throttle sign loss protection.
1.7 Separate programming port to effortlessly link the Light-emitting Diode system card towards ESC.
1.8 ESC development via portable Light-emitting Diode program card.
Requirements：
880 80A Brushed ESC
Cont./Burst Active: 80A/400A
Input：2-4s Lipo，5-12 Cells NiMH
Motor Type ：Brushed（540/550/775 size motors）
Automobiles Applicable：1/10&1/8 on-roads/Buggies/Trucks/Monster Trucks/Rock Crawlers & Some Ships
Motor Limit： ①2s lipo or 6cells NiMH ：540 or 550 size motor RPM＜[email protected] OR ≥12T
②3s lipo or 9cells NiMH ：540 or 550 size motor RPM＜[email protected] ≥18T
③4s lipo or 12cells NiMH ：540 or 550 size engine RPM＜[email protected] ≥24T
Built-in BEC:4A/6V(Change mode BEC)
Dimension&Weight:45.9*34.7*26.5mm/75g
Run mode：①forward & brake & reverse mode
② forward &reverse mode
③ ahead & brake
Programming Port ：Separate Port
