HOBBYWING XRotor Micro 30A BLHeli_32 DShot1200 - 30901077 Hobbywing好盈  [HW-30901077]

The use of high-performance 32-bit supply microprocessor (which operates at 48MHz),
brought in quality MOSFETs (Fairchild) & ceramic capacitors, 3-in-1 drive ICs,
3-ounce copper, 4 layers of PCBs, while the third-generation BLHeli (BLHeli_32 firmware)
produces an ESC with more functions & better performance specifically for FPV drones.

The ESC firmware uses hardware produced motor PWM for smooth throttle reaction and quiet
operation. Damped light does regenerative breaking, causing extremely fast engine retardation, therefore
inherently also does active freewheeling.

The original BLHeli_32 firmware allows users to get in touch four
ESCs on FC flashed because of the Cleanflight/Betaflight
firmware via sign cables (regarding the ESCs) setting general
parameters of this ESCs at the same time, update the firmware
or adjust higher level parameters on line in addition.

Multiple security functions like engine
lock-up protection, heat security,
low RPM energy protection, low-voltage
protection and current protection effectively
prolong the service life associated with ESC.

The light color associated with Light-emitting Diode indicator regarding the ESC is adjustable.
The Beacon functionality, that will drive the motor to beep in the event that throttle signal has
been zero for confirmed time, effortlessly helps finding lost crafts.

• Cont./Peak Current : 30A / 50A
• LiPo Cells : 2-5S Lipo
• BEC production : No

• Output Wires : No cables but solder tabs
• Input Connectors : No
• Output Connectors : No
• Firmware : BLHeli_32
• ESC Programming : Supported
• Stick Programming : BLHeliSuite
• DEO : Supported
• Throttle number Calibration : Supported
• Oneshot125 Mode : Supported
• Oneshot42 Mode : Supported
• MultiShot Mode : Supported
• Timing : Supported
• Motor Rotation : Supported

• Size : 23.8x14.5x5.8mm
• Weight : 6g

• 130-300mm FPVs
