High Performance Hardware &
Original Third-generation BLHeli_32 FirmwareThe usage of high-performance 32-bit ARM microprocessor (which operates at 48MHz),
brought in quality MOSFETs (Fairchild) & ceramic capacitors, 3-in-1 drive ICs,
3-ounce copper, 4 levels of PCBs, as well as the third-generation BLHeli (BLHeli_32 firmware)
produces an ESC with an increase of functions & better performance particularly for FPV drones.
Hardware Generated PWM & Damped Light ModeThe ESC firmware utilizes hardware created engine PWM for smooth throttle reaction and quiet
procedure. Damped light does regenerative breaking, causing extremely fast motor retardation, plus it
inherently also does active freewheeling.
Multiple Programmable ItemsThe original BLHeli_32 firmware permits users to get in touch four
ESCs to your FC flashed with all the Cleanflight/Betaflight
firmware via sign cables (in the ESCs) setting general
parameters regarding the ESCs at the same time, upgrade the firmware
or adjust advanced level parameters on line at the same time.
Multiple ProtectionsMultiple protection functions like motor
lock-up protection, heat security,
low RPM power security, low-voltage
security and current security effectively
prolong the solution life of the ESC.
Light-emitting Diode Indicator (only the XRotor 40A
BLHeli_32 has it) & Beacon FunctionalityThe light color regarding the Light-emitting Diode indicator in the ESC is adjustable.
The Beacon functionality, that'll drive the engine to beep if the throttle signal has
been zero for confirmed time, effortlessly assists finding lost crafts.
Specifications- Cont./Peak active : 40A / 60A
- LiPo Cells : 3-6S Lipo
- BEC Output : No
Wires & Connectors- Output Wires : No cables but solder tabs
- Input Connectors : No
- Output Connectors : No
- Firmware : BLHeli_32
- ESC Programming : Supported
- Stick Programming : BLHeliSuite
- DEO : Supported
- Throttle Range Calibration : Supported
- Oneshot125 Mode : Supported
- Oneshot42 Mode : Supported
- MultiShot Mode : Supported
- Timing : Supported
- Motor Rotation : Supported
Size & Weight- Size : 32.7x18.4x6.2mm
- Weight : 11.5g
Applications
