Serpent SER600039-B Serpent Cobra E-Truggy RTR Blue [SER600039-B]

價格:

HKD$2,828.87

牌子:

Serpent

型號:

SER600039-B

物品狀況:

全新

數量:

填寫評論

產品說明

Introduction

The Serpent Cobra E-Truggy in RTR trim is a perfect basher kind vehicle that will simply take some beating and its additionally an excellent package to begin real racing ! In line with the Cobra E-Truggy it has the outright speed, great maneuvering, reliability, rigidness and durability you'll need.

The RTR package is really dialed:
- factory put together rushing chassis
- prepainted and precut low kind truggy body and large composite back wing
- premounted truggy tyres/wheels/inserts
- pre-set 4S waterproof 150A speedo ( DragonRC)
- 2000kv brushless longbody motor (DragonRC)
- electronic 2.4ghz transmitter (DragonRC)
- Metal gear servo 16kg ( DragonRC-Savox)
- 3 oilfilled geardifferentials
- Big bore shocks with rubber dustboots and machined aluminium shocktowers
- Spring metal transmission parts and turnbuckles, front side and rear cvd driveshafts
- Front and rear anti-roll bars
- Large battery-cases with effortless felcron straps
- Machined aluminium chassisplate
- completely ballraced
- Batteries the vehicle and transmitter aren't included

The bodyshell will come in orange, red, green, blue and red, and a definite kind.

Serpent offers a multitude of optional components because of this vehicle to boost performance, lighter or for even nicer appears.
Available in 4 colors:
600039-O Serpent Cobra E-Truggy RTR orange
600039-R Serpent Cobra E-Truggy RTR red
600039-B Serpent Cobra E-Truggy RTR blue
600039-G Serpent Cobra E-Truggy RTR green
Main features

automobile
Fully expert pre put together and pre-set chassis and electronics.

Transmitter
DragonRc 2.4 GHz steeringwheel kind transmitter with lots settings and good range. Comes with small and light receiver.

Speedo
DragonRC waterproof speedcontroller with an enormous 150A ability to regulate the brushless engine and 4S battery power

Motor
DragonRC longbody 2000kV brushless engine with simple colorcoded connectors

Body
Prepainted and pre-cut low e-Truggy body, in 4 main colors orange, red, Green and Blue. ( additionally clear one available as optional)

Tyres
Premounted competition ready tyres / wheels with soft substances and pintype profile for incredible hold.

Chassis
extremely narrow 3mm 7075T6 aluminium chassis, with machining on upper face to make it lighter in strategic areas and also to control flex. Kick-up front for appropriate landings. Angled part to improve cornering approval, and protected and simple mounting part guards with 5 screws. Countersunk holes, pouches to put the suspension system brackets. Overall the Truggy was created to keep consitently the weight extremely main and towards the centerline that you can, to create a good overall stability.

part guards / battery trays
Durable shaped composite part guards / battery pack trays that proceed with the line of the chassis, and mount with 5 screws each part. Front and sides high enough to help keep the dirt away. The guards/trays create many stability. The batteries are installed in longtudinal fashion, maintaining the extra weight really low within the car. The battery trays features simple to use Serpent marked felcron TM straps to secure the batteries in position. Fits 2S and 3S batteries.

Motormount:
The motor is put within the most optimal place in automobile, maintaining motor-forces and transmission components / positioning in mind. Just one-screw is necessary to secure the BL engine, inside nicely designed durable machined aluminium motormount. Room for additional motor-cooling available as needed. The room for the motor enables mounting all popular buggy and (monster)truggy motors.

Composite chassis braces
Allows the framework to flex which helps improve bump control. Front side and back.

Front bumper
Nicely rounded front bumper, identical to on the Cobra buggy, to safeguard the front anti-roll club, suspension system brackets, and moves inline with kick-up framework front for safe landings.

Front suspension
Very long and durable composite reduced wishbones, coupled with top spring-steel trackrods. 2 reduced shock-mount positions. Downstops can be utilized as required. Pivotball kind anti-roll club rods.
.
Front steering / servo saver / angled
Innovative angled front steering set up to cut back the angle of distinction between the total caster and steering plane. Therefore you will have less bump steer and a truer steering Ackerman through the whole selection of suspension system.

Adjustable spring loaded servo-saver system with interchangeable Ackermann plates. With the design regarding the steering bell cranks when changing the Ackerman you won't should adjust your steering tie rods. You simply will simply have to adjust your end points on your own radio.. Very easy to access and set-up.

The Inboard Bell crank keeps the lever and linkage in the automobile. It'll assist in preventing damage to the steering system. Zero scrub radiuses on steering knuckle, helps reduce the jacking effect produced by your steering knuckle offset. It gives a far more direct dropped while maintaining the vehicles chassis more degree while turning.

the leading roll center can be changed quickly by going the steering knuckle shims for their appropriate locations.

Topped of with a very good composite top-plate.

Front steering-block / c-hubs
really durable front side steeringblock / C-hub assembly .

Drive-shafts
longer and lightweight springtime steel units with pressed in steel pins, laser-engraved. Same length front side and back.

Wheel-axles / wheel-nut
Serpent spring metal threaded wheel-axles with lightweight grey anodised aluminium wheel-nuts to help keep the huge truggy wheels/tyres on the right track.

Captured universal bones
Guarantees you certainly will finish a race without loosing a pin or set screw. All parts, axles and drive train components have capture pins

Front shocktower
Light, strong and durable machined 5mm aluminium devices with 5 roles for shockangle.

Shock-set front side and back
16mm big bore shocks, with hard anodized precision threaded shock-bodies. Shockboots in silicone rubber to help keep the dirt out . Chromed shock-shafts for supersmooth shockaction . The bigger o bands offer less general force and an improved seal without dragging on surprise shaft.

Suspension brackets
The hinge-pins / hingepin balls are captured in durable composite suspension system brackets . These capture the nylon roll-center inserts.

Anti-roll bar / anti-roll bar linkage with pivotball
The anti-roll pubs front and rear are constructed with top quality unique spring steel, and tend to be captured in the diff-cased in ballbearing for perfect guidance and control.

Receiver package / servo mount / speedo mount
Composite one piece radiobox to securely install servoï¿½ s, speedo and receiver. For optimum stability the light receiver fits the top-case effortless, with a little opening allowing cable to protrude. The speedo seats suprisingly low on a plate just above the framework, therefore quick cables could be used to the motor. The servo is installed in a vertical fashion.

Central diff
Optimised main gear-diff with 50T super-hard spur-gear . Tiny, compact design to cut back rotating mass towards the maximum.

Transmission shafts
Durable but light and slim Serpent spring metal, laser etched shafts.

Front and rear diff
Optimised gear-diff with superhard spur-gears . Very small, compact design to lessen rotating mass toward maximum. Same version front side and backside. Diff coupler in spring steel seated in big barings for durability.

back shocktower
Light, strong and durable machined 5mm aluminum product with 5 positions for shockangle.

Rear uprights
Durable composite rear uprights with 3 camber roles

Suspension brackets back
Durable composite units with eccentric inserts to alter set-up.

back wing mount
The composite rear wing mount, allows to improve the angle of the back wing.

Rear wing
Two phase high down force wing, has two degrees of angle, which also includes 2 fins. Helps improve down force and straight line ability

Bodymounts
Nylon bodymounts with wider seating the body, securely fastened to your shocktowers.

Super minimal profile e-Truck Body
Improves look along with keeps the profile low. Comes precut and prepainted.

Decals
placed on the body.

Oils / grease
automobile is assembled with a high quality silicone natural oils the diffs and shocks and black colored grease. Threadlock used where needed.

handbook
color manual showing the car, specs, guidelines and exploded views. The transmitter and speedo have actually small separate manuals included.

Box
color protective package to re-use for vehicle transportation or tyres.
