Tamiya 47454 - 1/10 Plasma Edge II Iridescent Purple/Green (TT-02B chassis) 田宮遙控模型越野車套件 雙星孖星  [47454]

• 產品說明
• •
  •
  •

This really is a Limited-Edition form of the Plasma Edge II off road buggy. Your body is pre-painted in Tamiya’s PS-46 Iridescent purple/green color. The body sits ahead the simple to build TT-02B framework for fun off-road driving!

Shaft-Driven 4WD TT-02B
The shaft-driven 4WD TT-02B buggy chassis makes use of a skid-shaped framework. Its suspension setup uses 4-wheel separate double wishbone suspension system with long arms, plus CVA surprise devices, providing the automobile assured handling, while left and right suspension system hands and uprights are identical to facilitate hassle-free construction. Front and rear gearboxes include 4-bevel differentials for smooth operation, and so are sealed to ensure dust can not get in. The most effective may be removed by loosening four screws, making maintenance a piece of cake. Four different gear ratios may be used if you use three separately-sold kinds of pinion gears, enabling you to match the faculties of the vehicle setup towards conditions at any moment. Of course, this off road framework also contains receiver situation and motor address to protect them from dirt and debris thrown up off the track.

• 1/10 scale R/C model assembly kit. Length: 370mm, width: 250mm, height: 160mm.
• Polycarbonate human body and wing are pre-painted in PS-46 Iridescent purple/green, and pre-cut.
• Stickers have actually a dedicated color scheme dedicated for this model.
• The TT-02B chassis may be the buggy evolution of Tamiya's popular 4WD basic level unit, the TT-02 framework.
• Bathtub-type framework has longitudinal battery pack and R/C device put flat for low center of gravity.
• 4-wheel double wishbone suspension features long arms and CVA surprise devices, and is along with high hold square increase tires that provide excellent traction.
• Front and rear gearboxes have actually gear differentials to ensure smooth cornering.
• an array of Hop-Up Option parts can be obtained to tune the TT-02B chassis.
• Includes 540-type motor.
• Includes Tamiya TBLE-02S ESC (electronic speed control) effective at running sensor brushless engines and brushed engines alike. (21.5 change BL engine restriction) (23 Turn brushed motor restriction).
• needs: 2-Channel broadcast, servo, 7.2-7.4volt battery power & appropriate charger.

Specification:

• Adjustable Gear Ratio : Yes
• Bearings : vinyl bushing
• Body Material : Polycarbonate pre-painted body
• Body Stickers : Included
• Chassis Material : ABS Plastic
• Chassis Type : TT-02B
• Construction Type : Assembly Kit
• Differential Type : Gear
• Drive Type : 4WD
• Electronic Speed Control (esc) : Includes Tamiya TBLE-02S ESC (electronic rate control) Capable of running sensor brushless engines and brushed engines alike. (21.5 Turn BL engine limit) (23 Turn brushed motor limit)
• engine : 540-brushed type
• Requires A : 2-channel radio, steering servo, 7.2volt battery pack & battery charger
• Scale : 1/10
• Shock Damper : CVA Oil Filled
• Suspension : 4-wheel fully independent double wishbone
• Terrain Use : Off-Road
