Tamiya 56301 - 1/14 R/C Tractor Truck King Hauler 田宮遙控模型貨櫃拖頭/車 雙星孖星  [56301]

This is a 1/14 Scale Tractor Truck by Tamiya that is a VERY Scale Kit. The semi trailer is Not one of them kit, but is available separately (or the tanker trailer, ). The King Hauler is a scale tractor truck with an authentic ladder framework and a 3-speed gearbox. The suspension system has solid axles with leafsprings just like complete scale vehicles..

Features:

• 3-speed transmission with constant mesh gears
• Metal train framework
• Scale suspension with high quality steel leaf-springs and coil springtime dampers
• Propeller-shaft driven backside axles (both axles are accustomed to drive the truck)
• Many scale human body accessories including steel grab rails and part mirror supports, metal dual exhaust pipelines and chrome plated parts (grille,fuel tanks, side actions, horns, wipers, visor, rims, bumpers, light mounts, mirrors and tire guards)
• Oilite bearings (bushings)

Specs:

• Scale: 1/14
• Length: 23.62 inches (600mm)
• Width: 7.20 ins (183mm)
• Wheelbase: 17.60 ins (447mm)
• Front Tread: 6.14 ins (156mm)
• Back Tread: 5.43 inches (138mm)
• Body weight: 6.17 pounds. (2800g)
• Chassis: Aluminum ladder
• Suspension: Solid Axle
• Damper Type: Steel friction
• Drive Train: Gearbox (3-speed)
• Gear Ratio: 10.6:1 - Using The 3-speed gearbox, 10.6:1, 17.7:1 and 32.4:1 are feasible
• Differential Type: Bevel Gear
• Engine: Electric 540
• Wheels & Tires: Chrome/Radial
• Physique: Styrene(plastic)
• Radio Control Unit: (perhaps not included) could be operated with a 2-channel radio but a 4-channel system is preferred for possible future options.

Includes:

• Injection molded human anatomy (white) and vehicle interior
• 10 scale appearance rims and tires
• 540 motor
• Decal sheet (with license dish decal for bumpers)
• Mud flaps
• Illustrated directions

Comments:

• If consumer desires bearings for this kit, they'll need twenty-six 5x11 and four 6x12.
• There was a light kit available separately for this vehicle, and a light kit readily available for the trailer,
• the primary distinction between the King Hauler and also the world Liner may be the human anatomy design.

Tractor Truck Kits Needs:

• 4CH Broadcast Systems w/ Servo(s)
• Recommand using Futaba Attack 4VWD 4-Channel AM 27MHZ/ R124H/ 3xS3003 transmitter set /Futaba 4YWD Transmitter
• 8 AA Batteries (For Transmitter)
• 6-Cell Battery (7.2V)
• Stick Pack (A/C/DC Charger)
• TS Paints
• Tools

Suggested Paint Colors:

• TS-39 - Mica Red
• X-11 - Chrome Silver
• X-18 - Semi Gloss Black
• XF-60 - Dark Yellow
