Tamiya 58489 - 1/10 RC High Performance 4WD Off Road Racer Avante 2011 田宮遙控模型越野車套件 雙星孖星  [58489]

In March 1988, Tamiya circulated an electrical R/C 4WD rushing buggy called the "Avante" and it has since become a particular machine in Tamiya&39;s R/C history. The equipment showcased a distinctive shaft-driven 4WD system that has been taken from Tamiya&39;s first 4WD R/C buggy, the Hotshot. It also showcased a highly advanced design including a FRP double-deck framework layout, longitudinal motor & battery roles, and a formula-type human body with framework fairing. It absolutely was equipped with innovative elements particularly a compact gearbox with 3 small planetary gears, a center diff to increase security, a fully adjustable suspension, and cam-lock wheel caps.

The Avante had been a unique R/C device which featured an innovative design. After two decades, a few of the Avante&39;s mechanisms are becoming standard features on modern R/C vehicles. The best pure racing buggy returns in 2011.

Tamiya has offered the Avante (2011) the unique re-release therapy like other re-released buggies like the Buggy Champ and Hotshot. The following is a short introduction for the improved points.

• Main framework material is changed from FRP to carbon fibre. Original FRP upper/lower decks were replaced with 2.0mm thick carbon fibre decks to further enhance chassis power and rigidity. Chassis layout is optimized for setting up contemporary R/C gear.
• Carbon Fiber back Damper Stay Rear damper stay is thicker than the original as well as its product has also been changed to carbon fiber. Kept and right remains are attached to further enhance rigidity.
• Assembly Universal Shafts WO universal shafts are utilized for both front and backside to lessen friction loss.
• Easier Damper repair The gold-colored oil damper cylinders feature base caps for easier maintenance including changing o-rings.
• Durable Polycarbonate Body Shell the human body, wing, and framework fairing have been made with polycarbonate for superb off road durability.
• Wheel Axle/Clamp Type Wheel Hubs Wheel axles have already been changed to standard pin-secured type. Together with aluminum wheel hubs, secure wheel accessory can be done. The hex wheel hubs help attachment of off-road tires such as Item 53880 big Dish Wheels (4WD/Front, 62/25) and Item 53881 Large Dish Tires (Rear, 62/35) besides the initial cam-lock kind tires.
• Duralumin front side knuckles the initial die-cast front knuckles were replaced with duralumin knuckles to help enhance durability and strength. New knuckles feature the exact same shape due to the fact original.Compatible with a wide selection of battery packs. The Avante (2011) is compatible with a variety of Tamiya battery pack products such as for example Ni-Cd, high-capacity Ni-MH, and lightweight LF battery packs.
• Latest R/C Systems The Avante works with Tamiya R/C systems such as the 2.4GHz systems.
• The Original Packaging is also Revived! The package with this re-release model is sold with the same design and dimensions due to the fact initial Avante. In addition, similar to the initial Avante, all of the parts are stored in blister packs.
• The "Avante" logo and back wing sticker will stay exactly like the original. Other stickers will likely be of a fresh Tamiya design.

Specs:

• Length: 420mm
• Width: 240mm
• Height: 115mm
• Wheelbase: 260mm
• Tread (L/R): 200mm
• Minimal Ground Clearance: 40mm
• Weight: 1300g
• Double-Deck Frame
• Tires (F/R): 38/88mm
• Polycarbonate Body
• F/R Multi-Link Suspension
• F/R Metal Oil Dampers
• Gear Ratio: 1:8.33

Features:

• Mini resin bumper.
• Front double wishbone suspension.
• Radius supply protector.
• Front stabilizer.
• Front strut towerbar for enhanced rigitity.
• Front C.V.A. oil damper with tapered coils springtime.
• Pin surge tire.
• Inner sponge.
• Cam-loc wheel.
• Steering tie rod.
• Universal joint.
• Front gearbox features compact planetary differential w/ steel pinion gear.
• Carbon upper deck, part of the double-deck chassis design.
• Steel propeller shaft.
• Steering servo (maybe not included).
• Polycarbonate undertray.
• Longitudaly-mounted engine.
• Receiver (not included).
• ESC (included).
• Back gearbox upper access hatch.
• Back steel C.V.A. damper product.
• Rear strut tower.
• Back double wishbone suspension.
• Back stabilizer.
• Adjustable wing mount.
• Polycarbonate human anatomy.
