Specifications:
•Based on IFMAR/ROAR/EFRA/BRCA design specs.
•Modified winds, 13.5T, 17.5T, 21.5T motors are typical ROAR authorized ( BRCA pending).
•Motor Dimensions (Diameter x size) 35.8mm x 52.2mm.
•Shaft Diameter: 3.17mm
•Magnet Measurements
12.3 x 5x 24.2mm(3.5T~9.5T),
12.5 x7.2x25.2mm (10.5T~21.5T),
12.3 x7.2x25.2mm (25.5T)
Variable timing end bell
•Weight: ~150g (varies between turns)
•Recommended RC Model Car: 1:10 touring, Buggy, MINI automobile.
Available Turns: 4.5T, 5.5T, 6.5T, 7.5T, 8.5T, 9.5T, 10.5T, 13.5T, 17.5T, 21.5T,25.5T - 3.5T purchase by request.
Improvements based on the Actinium V4 motor:
•Revised construction design for improved sensor precision.
•Revised stator dish profile with 3 screws holes sealed to improve magnetic field persistence and efficiency.
•Traditional three long assembly screws replaced with brief screws mounted to part of end bell.
•Copper wiring purity increased for minimized opposition. Hand wound for optimum precision and efficiency.
•Revised rotor magnetic product for improved power, effectiveness and extend the fade out time.
•Motor can machining profiles somewhat revised from V4 to enhance convection cooling.
•Collector band machined from proprietary alloy leading to minimal resistance and maximum temperature dissipation.
