Specifications:
- Controls: Forward/Brake/Reverse
- Input Voltage: 2S-3S lipo
- BEC: 6V/7.4V selection/max ~5A
- engine Limit: 4.0T or higher
- Max current: ~200A per phase
- Size: ~30.5x38x16mm
- fat: ~38g (maybe not consist of wiring and fan)
Hardware:
* Change to 32-bit MCU with ultra-smooth, faster reaction with precise throttle and stopping control. More upper end power with the same product function setup in comparison with Radon professional V4.1.
* brand new PCB layout and new interior hardware design raise the heat dissipation and may be around 10'C lower than radon pro v4.1 taking care of the same condition. The rate control cooling fan could be removed whenever operating small to medium track for modify/stock race.
* relate solely to outside Bluetooth device for higher level development and firmware up-date through the Mobile APPS. APPS is supposed to be available on both IOS and Android os.
* Real Time Data review through Cellphone APPS(active Input & Output Throttle, Temperature, RPM, Adv. Timing, Voltage and min. voltage, Max Temperature, RPM & Adv. Timing)
* Built-in one touch On/Off switch and support outside On/Off switch.Limit edition casing with Metallic golden color in open line
Features:
- 32bit-MCU with ultra-smooth, precise throttle and braking control
- appropriate for sensored/sensorless brushless engines
- relate genuinely to Bluetooth unit for advanced level programming and firmware change through mobile phone APPS (help Android os or Apple)
- Real Data research through Mobile APPS(Max, RPM, RPM, Advance Timing, Max Timing, Temperature, Max Temperature, minimal Voltage Low voltage and ESC temperature)
- Built-in one touch On/Off switch and help outside On/Off switch
- Bulit-in minimal voltage cut-off, Overheat protection and signal loss protection
-Ext. Bluetooth is optional and it is maybe not contained in the package.
