XRAY T4 2018 All-new Specs
  • All-new ULP (Ultra Low Profile) shocks with 4mm lower design for improved stability
  • All-new ultra-low profile ULP surprise towers to allow for new ULP (Ultra minimal Profile) shocks
  • All-new framework design with brand new engine mount dish position for further flex modification and engine moved more to center
  • All-new top redesigned top deck works together with this new layshaft bulkheads and engine mount which moves engine more to center
  • All-new engine mount dish features brand new additional rearmost holes for improved traction and further flex adjustment
  • All-new engine mount decreases the chassis roll with engine place more to center
  • All-new in-line chassis flex set-up choices
  • All-new ECS drive shafts are 51mm long for optimized steering and stability

General
  • Designed for highest performance at all degrees of racing
  • Chassis designed to provide maximum traction and steering
  • Reduced sensitiveness to changing track conditions, offering super-consistent performance during runs
  • EFRA, ROAR, FEMCA spec compliant for stock and modified racing
  • Super easy to build, setup, keep, and drive
  • Developed, designed and styled by Martin Hudy, produced solely by XRAY in European countries on earth's many advanced RC production facility
  • Revolutionary on-road platform aided by the standard for premium quality, dependability and performance
  • Premium, expert, high-competition model racing car for the many demanding racers
  • Manufactured from premium European materials, machined making use of advanced Swiss and German machines
  • Premium XRAY solution & support
Chassis
  • Graphite framework CNC-machined from 2.2mm premium-grade graphite material
  • Chassis created specifically for different track conditions, providing improved traction, steering, stability, and increased cornering speed
  • Chassis has pre-drilled holes for ARS system
  • Chassis features pre-drilled holes for optional parts such as framework weights, graphite engine guard, graphite adjustable battery owner, and battery pack strap
  • Chassis designed especially for brushless engines and LiPo batteries; composite battery pack holders prevent batteries from transferring crashes
  • Top deck permits installing optional aluminum stand to change flex characteristics, and optional graphite steering system plate
  • Bulkheads are strategically placed near to the center of this chassis to improve steering, traction, and stability
  • Layshaft bulkhead enables elimination of top deck accessory screws (bearing is held by layshaft bulkhead)
  • Upper bulkhead clamps feature 4 optimized roll center positions
  • Front & backside bulkheads enable separate front side & rear diff height adjustment and belt stress adjustment
  • 3mm super-low profile shock towers lower the CG and enhance stability
  • Motor mount bulkhead works along with industry-standard brushless motors
  • Centered layshaft and split bulkheads offer improved balance considering maximum fat distribution of the engine towards centerline, providing faster left-right transitions
  • Motor mount bulkhead is combined with layshaft bulkhead in 1 solid piece to remove tweak brought on by connected screws
  • Motor mount bulkhead is linked to aluminum motor mount dish to eliminate tweak, also provides numerous flex adjustment opportunities by adding/removing screw ahead or behind the nut, or by utilizing optional post as opposed to the nut
  • The engine mount plate is connected to the framework via an M3 nut and an additional countersunk screw could be put ahead or behind the nut if more reinforcement will become necessary, and/or nut can be eliminated and 1 or more of 6 holes can be utilized as additional flex adjustment options
  • Front & back reduced bulkheads take care of the anti-roll club bearing mounting system

Suspension
  • Kit includes both standard & ARS (Active back Suspension system) back suspensions
  • ARS suspension provides great adjustment possibilities and driving characteristics
  • ARS suspension system consists of ARSarms, graphite 0° C-hubs for optimal flex characteristics, difficult suspension system block, ARSsuspension block, and ARS linkage linking the owner towards suspension system block
  • ARS linkage angle – adjusted by adding/removing shims regarding the steering block and ARS-holder modifications the toe-in traits associated with the rear tires during chassis roll
  • Aluminum suspension system holders featuring incorporated Suspension Settings (ISS) for fast & effortless suspension geometry adjustment
  • Suspension holders allow stronger mounting of suspension hands, so the suspension system geometry of this car doesn't change even after difficult crashes
  • Suspension mounting system allows for really free supply motion, which provides higher traction, smoother driving, and improved steering
  • Suspension holder system permits suspension arms become mounted independently from bulkheads enabling elongated framework flex to build more traction
  • Independent suspension system holders enable more exact and fine set-up changes via various bushings
  • Rear suspension aluminum holders function integrated toe-in
  • C-hubs available optionally in standard caster perspectives (0°, 2°, 4°, 6°); obtainable in four hardnesses (M – medium, H – hard, G – graphite and aluminum)
  • Hard front steering obstructs increase steering reaction, decrease front tire overheating in high-traction conditions
  • Small, robust steering obstructs created from special proprietary composite product, available optionally in 3 hardnesses (M – medium, H – difficult, G – graphite and aluminum), and feature 2 Ackermann positions
  • Rear uprights give increased security; available optionally in 3 hardnesses (M – medium, H – difficult, G - graphite)
  • backside uprights function integrated 0° toe-in to stop suspension geometry alterations in severe crashes
  • Arms feature revolutionary SFATM (Suspension system Flex Adjustment), revolutionary and unique graphite stiffeners permit super-quick suspension flex modification to easily adjust the traction for the automobile under various track conditions
  • Suspension hands function incorporated anti-roll bar mounts; rear arms feature 3 various anti-roll bar mounts for super-fine modification for the back anti-roll bar
  • Suspension hands produced from graphite material for improved traction and stability associated with the car
  • Anti-roll bar system is installed to your bulkheads via bearings for extra-smooth motion and maximum precision, and side play is eliminated by aluminum bushings
  • Anti-roll bar height is adjustable via simple screw adjustment… fast & easy
  • Front 1.4 mm & back 1.3mm anti-roll bar cables included
  • Easily-adjustable wheel offset making use of optional wheel hubs (-0.75mm, +0.75mm, +1.5mm)

Drivetrain
  • Lightweight middle layshaft CNC-machined from aircraft aluminum
  • 84T 48P spur gear – extra-hard product, wobble-free design
  • 38/20T (1.9) interior gearing for efficient, high-performance drivetrain
  • Premium-qualitydrive belts
  • C-hubs with large spaces for fast & easy assembly/disassembly of the CVDs and ECS drive shafts; prevents collision of CVD or ECS drive shafts with C‑hub in severe crashes
  • Super-light drive axles
  • Front Extra-Strong ECS drive shafts equalize the speed between your drive shaft therefore the wheel. With a distinctive 2-piece joint between your axle as well as the wheel, any extreme wheel turning angle is divided into two shallower angles without joint binding. This means that whatever the cornering rate and wheel angle, the inner wheel wont bind or vibrate. Drive through corners is more stable, more precise, and better to drive
  • ECS drive shafts created from world-renowned, self-developed HUDY Spring metal hand ground for optimum precision
  • Super-lightweight Swiss 7075 T6 aluminum rear drive shafts (50mm), hard-anodized, color-coated and laser-engraved, 38percent lighter than standard drive shafts
  • Super-lightweight wheel axles made of premium HUDY Spring Steel
  • 7075 T6 aluminum wheel hubs
  • Complete set of high-speed, blue-sealed ball-bearings are degreased and gently oiled for maximum efficiency, separately managed, chosen, and inspected
  • Aluminum self-locking wheel peanuts

Differentials
  • Super-smooth, super-light maintenance-free composite gear differential
  • Adjustable gear differential stiffness via oil viscosity
  • Super-light composite Front Solid Axle with XRAY’s very own smart quick-change outdrive system for effortless outdrive trade; no servicing or replacement of drive shaft blades required, results in paid off servicing costs

Steering
  • Servo mounting system for improved balance and eradication of undesired tweak
  • Servo mount allows the servo become suspended to the framework centerline, providing better balance while eliminating tweak and allowing for extra traction
  • Steering is separated from framework flex, ensuring tweak-independent steering for super-precise and constant steering characteristics
  • Servo mount and graphite servo owner are mounted to your framework with 3 screws and 2 centering posts to eradicate the likelihood of servo movement under difficult crashes
  • Servo mount includes extra opening in which the battery pack backstop screw are mounted
  • Servo mount includes additional opening for in-line flex adjustment system

Shocks
  • Ultra- Low Profile (ULP) aluminum shocks even for lower CG and enhanced stability
  • ULP aluminum shocks have now been reduced by 4mm comparing to SLP shocks to give maximum security under all track conditions, while reducing traction roll under high-traction conditions and also to make the car better to drive
  • Shock shafts are especially hardened for maximum strength
  • Foam inserts for perfect surprise rebound
  • Super Short Shock Springs (4S) developed & created for the SLP shocks
  • C2.5 springs included in the kit to match ULP shocks while the springtime rates happen optimized to produce maximum steering and traction
  • XRAY self-developed and produced 4S springs are manually selected for optimum precision, equal size, and equal damping faculties
  • Race-tested and tuned shock roles

Bumper & Body Mounts
  • Front upper and lower composite bumper produced from specially-formulated product to withstand hard impacts
  • Super low-profile foam bumper created from lightweight, high-resilience foam
  • Foam bumper is bigger for perfect body fit
  • Foam bumper is manufactured out of strong but lightweight material for improved durability but keeping the extra weight only possible
  • Composite bumper top holder brace helps to reduce framework breakage in hard crashes

Assembly, Set-up, Support
  • Premium 3D full-color instructions & additional sheets
  • To completely understand the set-up opportunities we recommend the legendary HUDY Set-up Book (available for download solely at www.hudy.net) which is laden with over 50 pages of top-quality images and easy-to-understand RC vehicle set-up explanations
  • Exclusive Virtual on line Setup Sheet database with a large number of set-up sheets for battle songs around the world
  • Premium, unmatched XRAY on the web help

Adjustment Possibilities
  • Fully-adjustable front side and back suspension geometry: caster, camber, toe, anti-dive, anti-squat, ride height, droop, track-width, roll center, wheelbase
  • Adjustable gear differential tightness via oil viscosity
  • Four various top linkage jobs on top bulkhead clamps
  • Roll center height adjustment via shims on top bulkhead clamps
  • Adjustable front side and rear belt-tension control using quick-adjust system incorporated into bulkheads
  • Front and rear diff height adjustment utilizing quick-adjust system included into bulkheads
  • Adjustable HUDY aluminum turnbuckles (steering, front & back upper links, ARS)
  • Multiple top and reduced surprise mounting places at front side and rear
  • Adjustable Ackermann and bump steer
  • Pre-drilled chassis places for optional chassis loads in center of chassis
  • Adjustable front side and back anti-roll bars
  • Chassis pre-drilled holes for fat stability adjustment
  • Adjustable in-line flex system
