XRAY 320201 XT2 - 2018 Specs - 2WD 1/10 Electric Stadium Truck [XR-320201]

價格:

HKD$3,409.39

牌子:

XRAY

型號:

XR-320201

售罄

請輸入姓名和電子郵件地址。當貨品重新上架我們將笫一時間通知閣下.

你或可於 R/C Models - Off-Road - Truggy - Electric Powered
類別中嘗試尋找類似的產品

填寫評論

Dimensions

Chassis

Suspension

Suspension: Adjustable suspension system via built-in Suspension System I.S.S.
Rear suspension: Lower supply with adjustable top camber link
Front suspension: Lower arm with adjustable top camber link along with adjustable caster 0°, 2.5° and 5°
Rear upright: Composite 0° toe-in with double supply mounting and 7 roll center roles
Shocks: Membrane free surprise absorbers with Delrin pistons
Shock towers: Composite front side and back shock towers consist of multiple surprise positions (Carpet Edition) & graphite back surprise tower (Dirt Edition)
Drivetrain
Type: 2WD
Primary: Pinion / spur
Drive shafts: HUDY Spring metal CVD drive shafts
Differential: Sealed gear differential, 6 gear, silicone-filled (carpeting Edition), hard coated ball differential (Dirt Edition)
Slipper clutch: Adjustable 3-Pad
Bearings: Rubber-sealed high-speed bearings

Gearing

Geometry

Camber: Adjustable front + rear
Front Caster: 26° static + caster in caster block = 26°, 28.5°, 31° total caster range
Toe-in: Adjustable front + rear
Downstops: Adjustable front + rear
Front kick-up: Adjustable 26°~31°
Rear anti-squat: Adjustable 0°~4°
Anti-roll pubs: Front 1.4mm (1.2 mm, 1.6 mm & 1.8 mm option just), back - 1.0 mm to 2.0 mm (choice only)
Ackermann: Adjustable
Bump steer: Adjustable
Steering: Centrally-positioned double steering system

Body, Tires, Wheels & Misc

Adjustment Possibilities

Standard adjustment: Camber, toe-in, caster, track width, wheelbase, kick-up, anti-squat, roll center, Ackermann, bump steer
directions: Full-color manual with 3D layouts
Set-up book: Not included. HUDY 2-color off road set-up guide is downloaded within the down load area therefore shows 1/8 off road models in photographs contained within it. However, the methodology and set-up theory are exactly the same for several modern 1/10 off road automobiles.
Packaging: Carton package with plastic bags with parts
Additionally included: HUDY Graphite Grease, Silicone Oils, Authentication Certificate, Parts list & Exploded view, Decals

Products maybe not included

Radio system (transmitter and receiver), steering servo, engine, pinion gear, LiPo battery packages, speed controller, charger, tires, inserts, double-sided tape, CA glue, bearing oil, medium-grade (blue) threadlock, universal tool for all peanuts and turnbuckles alongside tools
