XRAY 320203 - Xray T2D 2019 - 2WD 1/10 Electric Stadium Truck - Dirt Edition   [XR-320203]

• Recent EOS Champion and United States Of America Champion platform
• All-in-one concept  includes particular components to build the XT2 for particular track conditions on either Carpet or Dirt:

- Both types of gearboxes and engine plates allowing positioning regarding the motor in reduced place (Carpet) or upper place (Dirt)

- Gear differential (carpeting) and ball differential (Dirt)

- Two various hardness of suspension system hands: medium (Dirt), difficult (carpeting)

- Two various back surprise towers: composite (Carpet), graphite (Dirt)

- Both forms of composite battery straps to match two various gear boxes

- Both types of composite mounts for top brace to match two various gear containers

- Composite gear address to guard kit field from dirt

• Brand New shorter front composite framework front side brace enables mounting of new graphite part guard brace to regulate front framework flex
• New graphite framework side guard brace for increased stability and performance
• New secure steering linkage mounting increases reliability regarding the steering assembly
• New surprise absorber lower shims give more exact shock shaft movement
• New surprise absorber O-rings for better sealing and shock performance
• New suspension pin washers stop the suspension system pins from coming out, increasing reliability

• Recent EOS Champion and United States Of America Champion platform
• All-in-one concept  includes particular parts to build the XT2 for particular track conditions on either Carpet or Dirt:
• Both types of gearboxes and engine plates enabling positioning of this motor in lower place (Carpet version) or top position (Dirt Edition)
• Gear differential (carpeting Edition) and ball differential (Dirt Edition) included
• Based regarding ultra-successful XB2 platform
• Full compatibility and interchangeable parts
• Designed for greatest performance anyway quantities of racing
• Engineered with focus on smallest details
• Manufactured with renowned artistic craftsmanship from premium European materials
• EFRA, ROAR, FEMCA spec compliant
• Super simple to build, put up, maintain, and drive
• Developed, created, and styled by European Champion Martin Bayer and Dipl. Eng. Juraj Hudy, manufactured solely by XRAY in European Countries on the planet's most advanced RC manufacturing facility
• Setting the newest benchmark for premium quality, dependability and performance
• Premium XRAY solution & help

• Optimal chassis fat distribution & balance
• Both forms of gearboxes and engine plates allowing placement regarding the motor in reduced position (Carpet Edition) or upper place (Dirt Edition)Original XRAY Multi-Flex™ technology for simple chassis flex adjustment
• Swiss 7075 T6 hardcoated 2.0mm aluminum framework: lightweight, strong, rigid
• Electronics design allows for moving the batteries frontwards/rearwards, and using standard or mid-size servos and either utilizing seat pack or short pack batteries
• Composite part guards are an integral part of the XT2 Multi-Flex™ system
• Shorter front composite chassis front side brace enables mounting of new graphite part guard brace to modify front framework flex
• Custom-designed front lower framework brace, obtainable in medium and difficult hardness for particular track conditions
• Front security bumper
• Custom-designed upper deck, obtainable in medium and difficult hardness for specific track conditions
• Swiss 7075 T6 aluminum motor plate
• Both kinds of composite battery pack straps to fit two different gear boxes with foam spacer
• Lightweight, strong composite surprise towers with numerous shock mounting positions (Carpet Edition) & graphite rear surprise tower (Dirt Edition)
• Pre-drilled centerline holes for simple balancing using the HUDY Chassis Balancing Tool #107880

• Conventional gear-driven 2WD off-road stadium truck
• Unique gear package, Gear Box and engine Plate with lowered top shaft, forward-shifted engine for improved steering and managing on higher-traction surfaces
• Included rear gear differential with adjustable oil viscosity, 53T gear & internal satellite gears (Carpet Edition)
• Included externally-adjustable ball differential, 53T gear & axial bearings (Dirt Edition)36T (Carpet Edition) & 25T (dust Edition) graphite composite idler gears
• 20T super-lightweight Swiss 7075 T6 hardcoated aluminum top shaft
• Robust slip-adjustable clutch with 81T primary spur gear molded from exclusive key mixture of composite material
• 3-pad slipper clutch with ultra-efficient SLS product for lots more efficient & precise slide adjustment, and HUDY Spring Steel™ hardened outdrives for additional lifespan and reliability
• Constant velocity drives (CVD) are made of special HUDY Spring Steel™ for reduced weight and increased durability
• Ultra-lightweight 12mm wheel hex drive hubs CNC-machined from Swiss 7075 T6 and additionally black-coated have actually ultra-true hex clamping design which guarantees solid mounting of the wheel
• Full pair of 22 high-speed, blue-sealed ball-bearings are employed throughout the drivetrain to make sure maximum effectiveness, degreased and oiled with AeroShell® Fluid 12 for optimum smoothness and endurance

• Integrated Suspension Settings (I.S.S.) for quick & simple suspension system geometry establishing utilizing eccentric bushings placed into Swiss 7075 T6 aluminum suspension system holders
• Specially-designed suspension components made of very carefully formulated custom composite mixtures to make certain proper flex and durability
• Race-perfected suspension geometry for superior performance and flexibility in every race conditions.
• Suspension hands are available in medium, hard and graphite hardness for certain track conditions
• Suspension components: steering obstructs, caster blocks and uprights are available in medium and hard hardness for certain track conditions
• Lower composite supply mount with integrated 26° kick-up angle; optional aluminum and brass arm mounts available
• Lightweight, rigid caster obstructs can achieve various overall caster perspectives utilizing included caster bushings
• Tiny yet tough steering blocks comprised of composite steering obstructs + graphite Ackermann extensions
• Adjustable weight stability & wheelbase via included shims on exterior suspension system pins
• Compact backside uprights with 0° toe and 6 different top roll center positions
• HUDY Spring Steel™ product for turnbuckles (featuring a tougher core) is used for front & rear upright linkages, and steering system.
• Front anti-roll bar made of special spring steel product to stabilize the vehicle at front side is installed towards the front body mount & can be simply adjusted via linkages; laser-engraved markings for simple recognition, for sale in different sizes for fine-tuning
• Optionally available backside anti-roll club set to stabilize the rear of the automobile; effortlessly modified via linkages; laser-engraved markings for effortless identification, obtainable in different sizes for fine-tuning
• Suspension pin washers avoid the suspension system pins from being released, increasing dependability

• Simple yet effective dual-arm steering system
• Secure steering linkage mounting increases dependability regarding the steering assembly
• Fully bearing-equipped with 8 high-speed ball-bearings for really precise steering
• Easily-adjustable Ackermann by fast changing the steering website link mounting jobs regarding steering plate
• Bump steer adjustment for lots more aggression
• Ackermann adjustment via included shims or making use of different graphite extension dishes on steering blocks

• constant, dependable, membrane-free shocks with bleed-screw shock limit design feature up-stop & downstop adjustment via shims (under shock collar, and under pistons, respectively)
• Swiss 7075 T6 aluminum shock figures, reduced nut & bleeder shock caps
• Super-precise molded Delrin™ pistons can be found with 2-hole & different diameters (1.6mm & 1.7mm) for precise shock adjustment, for custom modification, some blank pistons (no holes) may included
• Shock rods are machined from a unique metal material, accuracy hand-ground for optimum smooth procedure not to mention hardened for increased lifespan
• Premium surprise springs created specifically to complement the XT2 shocks; by hand measured, chosen and matched into pairs to guarantee equal length and damping faculties; laser engraved for simple identification
• Full distinct linear -or- modern shock springs available
• Premium silicone natural oils laboratory tested and calibrated to make certain maximum persistence and quality

• High-downforce, low-profile aerodynamic Lexan™ human anatomy built to completely fit the XT2, features high-downforce areas (including front screen and top roof flow stations) for proper air flow, and side downforce areas for greater stability.
• Tough composite side guards function double-sided Velcro™ tape to seal the human body completely towards the chassis and seal against dirt.
• Effective back wing had been designed to work perfectly because of the XRAY XT2 human anatomy. Produced from strong Lexan™ material, the wing is supported on wing mounts by extra flat shims to higher support and extend living of this wing.
• Specially created 12mm hex hub wheels for high-competition race; featuring reinforcement ribs to eliminate deformation and molded from extremely flexible product to retain form even after effects (available as choice only)

• Premium 3D full-color instructions & supplementary sheets
• To completely understand the set-up opportunities we recommend the popular HUDY Set-up Book that will be laden up with over 40 pages of high-quality images and easy-to-read RC car set-up explanations
• Exclusive Virtual on the web Setup Sheet database with thousands of set-up sheets for race songs across the world
• Premium, unmatched XRAY on the web support

• Fully-adjustable front and back suspension system geometry: caster, camber, back toe, kick-up, anti-squat, ride height, downstops, track-width, roll center, wheelbase, Multi-Flex™
• Adjustable back differential action
• Adjustable slipper clutch
• Adjustable HUDY Sprint Steel™ turnbuckles (steering, front & back top links)
• Multiple upper & reduced shock mounting locations at front & rear
• Adjustable Ackermann and bumpsteer
• Adjustable front anti-roll bar
• Optional adjustable backside anti-roll bar
• Chassis pre-drilled holes for fat balance modification
