XRAY 360006 - Xray XB4'19 - 4WD 1/10 Electric Off-road Car [XR-360006]

價格:

HKD$4,599.30

牌子:

XRAY

型號:

XR-360006

售罄

請輸入姓名和電子郵件地址。當貨品重新上架我們將笫一時間通知閣下.

你或可於 R/C Models - Off-Road - Buggy - Electric Powered
類別中嘗試尋找類似的產品

填寫評論

alt="XRAY 360006 - Xray XB4'19 - 4WD 1/10 Electric Off-road Car" title="XRAY 360006 - Xray XB4'19 - 4WD 1/10 Electric Off-road Car"

產品說明

XRAY XB4â19

2018 All-new:

Recent EOS Champion, European Champion, United States Of America Champion and World Champion platform
Redesigned framework accommodates brand new reduced engine mount to diminish the CG
Lower engine mounts reduce steadily the weight place of motor and central slipper clutch/diff, improving cornering rate and stability
Redesigned reduced composite core bulkhead fits the newest lower aluminum engine mount
Redesigned part guard allows engine become placed lower
Improved shock absorber lower shims give more accurate surprise shaft movement
Improved construction and manufacturing information on both front & rear differential crown gears results in quieter operation and increased reliability

General:

Designed for greatest performance anyway quantities of racing
Engineered with attention to smallest details
Manufactured with popular artistic craftsmanship from premium European materials
EFRA, ROAR, FEMCA spec compliant for stock and modified racing
Super simple to build, arranged, maintain, and drive
Developed, designed and styled by Dipl. Eng. Juraj Hudy, produced exclusively by XRAY in European Countries on the planet's most advanced RC manufacturing facility
Revolutionary off-road platform with brand new standard for premium quality, dependability and performance
Premium XRAY service & help

Chassis:

Smarter framework weight balancing options permit the engine mount and center diff set up to go frontwards or backwards
Unique XRAY Multi-FlexTM technology for effortless framework flex adjustment
Swiss 7075 T6 hardcoated 2.0mm aluminum chassis with countersunk holes for flush, smooth underside
Tough composite side guards completely fit the chassis to seal against dust and guard against side impacts
Compact electronic devices dish allows for mounting the speed controller for quick & easy elimination and assembly
Graphite front, main & rear top decks independent from framework flex adjustment and work only included in the front, main, and back diff assemblies
Composite & graphite chassis braces for fine-tuning associated with framework flex
Independent servo mount permits the steering servo to be mounted towards framework without pressing it, ensuring the reduction of undesirable framework tweak and enhancement of overall traction
Two different battery straps brief -or- long included. The long battery pack band enables battery pack to be set up either frontwards or rearwards
Battery foam right back spacer guarantees the battery pack will not fall out
Thick 3.5mm graphite front surprise tower & 3.0mm back surprise tower with numerous shock mounting and roll center positions
Extra robust front side & backside bulkheads allow use of the differentials only using 4 screws

Differentials & Drivetrain:

Front & backside gear differentials with adjustable oil viscosity, featuring 35T crown metal gears and 14T steel pinion gears
Molded front & back gear differentials for super-smooth, maintenance-free operation, features long-lifespan HUDY Spring Steelâ¢ outdrives

Innovative aluminum engine mount allows frontwards or rearwards engine place for weight stability adjustment
Motor eccentric mounting dish inserts into an integral engine holder/drivetrain help, allowing quick & easy engine rotation for gear mesh and safe clamping with just one screw

Robust central slip-adjustable clutch with 81T main spur gear molded from exclusive key blend of composite material
Internal 1:2.5 drive ratio
3-pad slipper clutch with ultra-efficient SLS material for more efficient & accurate slide adjustment, and HUDY Spring Steelâ¢ hardened outdrives for additional lifespan and reliability
Constant velocity drives (CVD) are produced from unique HUDY Spring metal for reduced fat and increased durability. The shafts are hand ground for maximum precision
Safety collars for several CVD drive shafts to help keep mounting pins securely in place
Ultra-lightweight 12mm wheel hex drive hubs CNC-machined from Swiss 7075 T6 and additionally black-coated have ultra-true hex clamping design which ensures solid mounting of the wheel
Optional 14mm offset wheel hex drive hubs available for super-fine track-width modification: -0.75mm, 0mm, +0.75mm and 12mm optional wheel hex drive hubs: -0.75mm, +0.75mm, +1.5mm, +2.25mm, +3.00mm, +3.75mm, +4.5mm
Full pair of 22 high-speed, blue-sealed ball-bearings utilized throughout the drivetrain to make sure maximum effectiveness, degreased and oiled with Aero ShellÂ® Fluid 12 for maximum smoothness and longevity

Suspension:

Swiss 7075 T6 aluminum suspension system holders front and rear
Integrated Suspension system Settings (I.S.S.) for quick & effortless suspension system geometry establishing using eccentric bushings inserted into aluminum suspension system holders
Specially-designed suspension components manufactured from carefully formulated custom composite mixtures to make sure proper flex and durability
Race-perfected suspension system geometry for superior performance and versatility in all race conditions.
Lightweight 1-piece caster obstructs with preset 9Â° caster with simple adjustable roll center position featuring larger openings for quick and easy disassembly of CVDs; optional 6Â° & 12Â° caster obstructs available
Front chassis feature pre-angled caster of 8Â° along with the adjustable I.S.S. settings a variety 16~20Â° of total caster can be achieved
Tiny yet robust steering obstructs molded from a special composite mixture for maximum power featuring adjustable reduced roll center.
Very compact 0Â° toe-in back uprights function 3 different upper roll center roles, staggered inner/outer bearing sizes for improved load help and unsprung fat, and wheelbase adjustability via included shims
Oversized external bearings in uprights to for increased powerful loads
HUDY Spring SteelTM material for turnbuckles (featuring a tougher core) is used for front side & rear upright linkages, steering system, and servo saver
Anti-roll bars manufactured from unique springtime steel material to support the car at both front side and backside are installed on diff cases & can be simply modified via linkages; laser-engraved markings for easy identification, for sale in different sizes for fine-tuning

Steering:

Simple, effective dual-arm steering system with integrated adjustable servo saver ensures perfect steering and easy Ackermann and bump steer adjustment

Shocks:

Consistent, dependable membrane-free big-bore shocks with bleed-screw shock cap design feature up-stop shock pole travel modification (via O-rings) and downstop modification (via shims under pistons)
Swiss 7075 T6 aluminum shock bodies, lower nut & bleeder surprise caps are hard coated
Super-precise molded Delrinâ¢ pistons are offered with 2-hole design & gap diameters 1.6mm and 1.7mm for precise shock adjustment; for customized adjustment, a set of blank pistons (no holes) may included
Shock rods are machined from a unique steel material, precision hand-ground for optimum smooth operation not to mention hardened for increased lifetime
Shock springs are faster to allow more fine trip height modification; by hand measured, chosen and matched into pairs to ensure equal size and damping characteristics; laser etched for easy recognition. Two forms of springtime sets are within the kit.
Full line of linear -or- progressive surprise springs available
Premium silicone oils laboratory tested and calibrated to make certain highest possible persistence and quality

Bumper, Body, Wheels:

Strong composite rear wing holder
Front reduced bumper protrudes from the base associated with chassis to soak up all impacts from contact involving the chassis and the track surface
Beefy 6mm thick body articles from unique composite product for maximum strength
High-downforce XB4 body is high-performance, low-profile, and aerodynamic to perfectly fit the XB4 layout, with front window and top roof flow stations for proper venting, and side downforce areas and top central rib for greater stability
Specially created 12mm hex hub wheels for high-competition race; featuring reinforcement ribs to get rid of deformation and molded from really flexible product to retain shape even after effects

Assembly, Set-up & Support:

Premium 3D full-color Instruction Manual & supplementary sheets
To fully understand the set-up opportunities we suggest the renowned HUDY Set-up Book which can be laden with over 40 pages of high-quality images and easy-to-read RC vehicle set-up explanations
Exclusive Virtual On Line Setup Sheet database with tens and thousands of set-up sheets for competition tracks across the world
Premium, unmatched XRAY online help

Modification opportunities:

Fully-adjustable front side and rear suspension system geometry: caster, camber, toe, kick-up, anti-squat, ride height, downstops, track-width, roll center, wheelbase, roll facilities, Multi-Flexâ¢
Adjustable front side & rear gear differential action (via oil viscosity)
Adjustable slipper clutch
Adjustable HUDY Sprint Steelâ¢ turnbuckles (steering, front & rear top links)
several upper & lower surprise mounting locations at front side & rear
Adjustable Ackermann and bumpsteer
Adjustable front & rear anti-roll bars
Chassis pre-drilled holes for fat balance adjustment

Dimensions
Class:	1/10 electric 4WD off-road automobile
Width:	Adjustable 245-250mm
Length:	350 mm
Wheelbase:	Adjustable 279-281 mm
Body Weight:	850 g
Ready-to-run weight:	1650 g
Chassis
Chassis:	CNC-machined Swiss 7075 T6 aluminum 2.0mm
Front upper deck:	Machined 2.0 mm laminated carbon graphite
Suspension System
Suspension:	Adjustable suspension system via Integrated Suspension System I.S.S.
Rear suspension:	Lower arm with adjustable upper camber link
Front suspension system:	Lower supply with adjustable top camber link sufficient reason for 9Â° caster obstructs
Back upright:	Composite 0Â° toe-in with twin arm mounting and 3 roll center roles
Shocks:	Big bore membrane layer free surprise absorbers with Delrin pistons
Shock towers:	Machined 3.5 & 3.0 mm laminated carbon graphite (front & backside) with multiple shock mounting and camber website link roll center jobs
Drivetrain
Type:	Full-time shaft-drive 4WD
Primary:	Pinion / spur
Drive shafts:	HUDY Spring Steelâ¢ CVD drive shafts
Central shafts:	HUDY Spring Steelâ¢ Direct Connection Shaftsâ¢
Differentials:	Sealed gear differential, 6 gear, silicone-filled
Slipper clutch:	Adjustable 3-Pad
Bearings:	Rubber-sealed high-speed bearings
Gearing
Primary ratio:	1:2.5
Differential pinion:	14T front / back
Differential crown gear:	35T front side / rear
Spur gear:	81T
Engine pinion:	Not included
Geometry
Camber:	Adjustable front side + backside
Front Caster:	9Â° fixed +7~11Â° caster in framework = 16Â°~20Â° total caster range Optional 6Â° static +7~11Â° caster in framework = 13Â°~17Â° total caster range Optional 12Â° fixed +7~11Â° caster in chassis = 19Â°~23Â° total caster range
Toe-in:	Adjustable front side + backside
Downstops:	Adjustable front + backside
Front kick-up:	Adjustable 7Â° ~ 11Â°
Back anti-squat:	Adjustable 1Â° ~ 5Â°
Anti-roll bars:	1.3mm front / 1.2mm backside
Ackermann:	Adjustable
Bump steer:	Adjustable
Steering:	Centrally-positioned double steering system
Body, Tires, Wheels & Misc
Body:	XRAY XB4 human body wide V2
Tires:	Maybe not included
Wheels:	XRAY Aerodisk 12mm Wheel hex hub
Adjustment Possibilities
Standard adjustment:	Camber, toe-in, caster, track width, wheelbase, kick-up, anti-squat, roll center, Ackermann, bump steer
Guidelines:	Full-color manual with 3D pictures (40 pages)
Set-up guide:	Perhaps not included. HUDY 2-color off road set-up guide (40 pages) is downloaded within the âDownload sectionâ therefore shows 1/8 off road models in photographs included within it. However, the methodology and set-up theory are the same for all contemporary 1/10 off-road vehicles.
Packaging:	Carton package with plastic bags with components
Also included	HUDY Graphite Grease, Silicone natural oils, Authentication Certificate, Parts list & Exploded view, Decals
Things perhaps not Included
Radio system (transmitter and receiver), steering servo, motor, pinion gear, LiPo battery pack packs, speed controller, charger, tires, inserts, double-sided tape, CA glue, bearing oil, medium-grade (blue) threadlock, universal tool for many nuts and turnbuckles as well as other tools
