XRAY 370007 X12 2018 EU Specs   [XR-370007]

XRAY 370007 X12 2018 EU Specs
價格:
HKD$2,682.00
牌子:
XRAY
型號:
XR-370007
請輸入姓名和電子郵件地址。當貨品重新上架我們將笫一時間通知閣下.
你或可於 R/C Models - On-Road - Pan Cars
類別中嘗試尋找類似的產品
填寫評論
alt="XRAY 370007 X12 2018 EU Specs" title="XRAY 370007 X12 2018 EU Specs"
alt="XRAY 370007 X12 2018 EU Specs" title="XRAY 370007 X12 2018 EU Specs"
alt="XRAY 370007 X12 2018 EU Specs" title="XRAY 370007 X12 2018 EU Specs"
alt="XRAY 370007 X12 2018 EU Specs" title="XRAY 370007 X12 2018 EU Specs"
alt="XRAY 370007 X12 2018 EU Specs" title="XRAY 370007 X12 2018 EU Specs"
alt="XRAY 370007 X12 2018 EU Specs" title="XRAY 370007 X12 2018 EU Specs"
alt="XRAY 370007 X12 2018 EU Specs" title="XRAY 370007 X12 2018 EU Specs"
alt="XRAY 370007 X12 2018 EU Specs" title="XRAY 370007 X12 2018 EU Specs"
alt="XRAY 370007 X12 2018 EU Specs" title="XRAY 370007 X12 2018 EU Specs"
alt="XRAY 370007 X12 2018 EU Specs" title="XRAY 370007 X12 2018 EU Specs"
Dimensions
  • Class: 1/12 electric pan car
  • Width: Adjustable 167mm +/- 2mm front side, 169mm rear
  • Length: 264mm (varies according to rear tires utilized)
  • Wheelbase: 201 +/-0.5mm
  • Weight: 202 g
  • Ready-to-run fat: 840 g - incl. BL system (varies dependent on gear utilized)


Chassis
  • Chassis: EU version - 2.5mm carbon fibre, CNC machined; US edition - 2.0mm Swiss 7075 T6 aluminum, CNC machined
  • Body: maybe not included, makes use of 1/12 pan vehicle kind


Drivetrain
  • Type: 2WD direct drive to rear axle
  • Rear Axle: Graphite shaft with ball differential
  • Primary: Spur/pinion
  • Bearings: High-speed ball-bearings (10)


Suspension
  • Front: Spring-supported, kingpin-style front suspension system with upper & reduced suspension system arms and steering blocks
  • Rear: Articulating rear motor POD adjustable via pivot-ball links, managed by rear surprise absorber.
  • Rear Shock: Central adjustable oil-filled surprise absorber


Geometry
  • Ride Height: Adjustable front + back
  • Wheelbase: Adjustable
  • Camber Adjustable front
  • Front Caster (Static): 1–14.5° fixed adjustable fixed caster
  • Front Caster (Reactive) 2.5–7.5° adjustable reactive caster
  • Track-width: Adjustable front side and rear
  • Toe: Adjustable front
  • Downstop: Adjustable rear
  • Ackermann: Adjustable with shims
  • Bumpsteer: Adjustable with shims
  • Steering: Direct linkage between steering servo saver and steering obstructs
  • Balance: Front/rear fat balance adjustable via battery pack position


Other
  • Wheels: perhaps not included
  • Tires: perhaps not included
  • Instructions: Full-color instructions with 3D layouts
  • Set-up guide: Printed variation perhaps not included. Latest full-color Set-up guide (16 pages) is downloaded from XRAY web site. Set-up Book shows previous XRAY models in photographs included within it, however the methodology and set-up theory are the same for several 1/12 pan cars.
  • Packaging: Carton box with vinyl bags with parts
  • Additionally included: HUDY Diff Grease, Authentication Certificate, components list & exploded view, decals, oils
  • Not included: engine, batteries, speed controller, tires, body, steering servo, radio equipment, tools
