XRAY 370008 X12 2018 US Specs   [XR-370008]

XRAY 370008 X12 2018 US Specs
價格:
HKD$2,682.00
牌子:
XRAY
型號:
XR-370008
請輸入姓名和電子郵件地址。當貨品重新上架我們將笫一時間通知閣下.
你或可於 R/C Models - On-Road - Pan Cars
類別中嘗試尋找類似的產品
填寫評論
alt="XRAY 370008 X12 2018 US Specs" title="XRAY 370008 X12 2018 US Specs"
alt="XRAY 370008 X12 2018 US Specs" title="XRAY 370008 X12 2018 US Specs"
alt="XRAY 370008 X12 2018 US Specs" title="XRAY 370008 X12 2018 US Specs"
alt="XRAY 370008 X12 2018 US Specs" title="XRAY 370008 X12 2018 US Specs"
alt="XRAY 370008 X12 2018 US Specs" title="XRAY 370008 X12 2018 US Specs"
alt="XRAY 370008 X12 2018 US Specs" title="XRAY 370008 X12 2018 US Specs"
alt="XRAY 370008 X12 2018 US Specs" title="XRAY 370008 X12 2018 US Specs"
alt="XRAY 370008 X12 2018 US Specs" title="XRAY 370008 X12 2018 US Specs"
alt="XRAY 370008 X12 2018 US Specs" title="XRAY 370008 X12 2018 US Specs"
alt="XRAY 370008 X12 2018 US Specs" title="XRAY 370008 X12 2018 US Specs"
Dimensions
  • Class: 1/12 electric pan car
  • Width: Adjustable 167mm +/- 2mm front, 169mm rear
  • Length: 264mm (varies dependent on rear tires utilized)
  • Wheelbase: 201 +/-0.5mm
  • Weight: 202 g
  • Ready-to-run fat: 840 g - incl. BL system (varies dependent on gear used)


Chassis
  • Chassis: EU edition - 2.5mm carbon dietary fiber, CNC machined; United States version - 2.0mm Swiss 7075 T6 aluminum, CNC machined
  • Body: maybe not included, makes use of 1/12 pan car kind


Drivetrain
  • Type: 2WD direct drive to rear axle
  • Rear Axle: Graphite shaft with ball differential
  • Primary: Spur/pinion
  • Bearings: High-speed ball-bearings (10)


Suspension
  • Front: Spring-supported, kingpin-style front suspension with upper & lower suspension arms and steering blocks
  • Rear: Articulating rear engine POD adjustable via pivot-ball links, controlled by rear surprise absorber.
  • Rear Shock: Central adjustable oil-filled shock absorber


Geometry
  • Ride Height: Adjustable front + rear
  • Wheelbase: Adjustable
  • Camber Adjustable front
  • Front Caster (Static): 1–14.5° fixed adjustable fixed caster
  • Front Caster (Reactive) 2.5–7.5° adjustable reactive caster
  • Track-width: Adjustable front side and rear
  • Toe: Adjustable front
  • Downstop: Adjustable rear
  • Ackermann: Adjustable with shims
  • Bumpsteer: Adjustable with shims
  • Steering: Direct linkage between steering servo saver and steering blocks
  • Balance: Front/rear weight stability adjustable via battery position


Other
  • Wheels: maybe not included
  • Tires: maybe not included
  • guidelines: Full-color instructions with 3D images
  • Set-up book: Printed version perhaps not included. Latest full-color Set-up guide (16 pages) are downloaded from XRAY website. Set-up Book shows previous XRAY models in photographs included within it, nevertheless the methodology and set-up theory are exactly the same for several 1/12 pan automobiles.
  • Packaging: Carton package with plastic bags with parts
  • Additionally included: HUDY Diff Grease, Authentication Certificate, components list & exploded view, decals, oils
  • Not included: engine, batteries, rate controller, tires, human body, steering servo, radio gear, tools
備註 :
由於庫存數量有限, 某些 XRAY 產品可能要特別從製造商訂購, 所需準備時間約為4-6週, 如我們庫存未能提供訂單上的某些產品, 我們將直接為客人從製造商訂購而買家須接受該所需的準備時間。
