XRAY X12



2019 All-new Specs
  • All-new EU and US Edition both created & optimized for specific traction conditions
  • All-new EU Edition is optimized for low-, medium-, and high-traction conditions
  • All-new US Edition is optimized for high- and very-high traction conditions
  • All-new 2.5mm graphite chassis for EU Edition with battery backstop grooves
  • All-new 2.0mm Swiss 7075 T6 aluminum framework with battery backstop grooves
  • All-new rear wheelbase adjustment
  • All-new upper clamps with composite bushing for better durability
  • All-new bulkheads work with new top clamps
  • All-new graphite backside brace with built-in backstop and O-ring battery mount system
  • All-new O-ring for securing the battery
  • All-new adjustable graphite battery backstop with 4 positions
  • All-new longer front graphite bumper owner



General
  • XRAY 1/12 pan-car with authentic 100per cent self-developed XRAY parts, created and manufactured by XRAY in Europe
  • Legendary XRAY premium design, workmanship & product quality and unmatched attention to the best details
  • Simple yet effective and proven design, well thought-out details, unmatched precision of all tiny details
  • High-competition design with focus on ultra-low weight, resulting in super-lightweight construction
  • Optimized for indoor carpet race as well as outdoor asphalt rushing



Chassis
  • EU Edition featuring CNC-machined framework from stiff custom-manufactured 2.5mm high-grade graphite product with specially-designed compound for carpeting and asphalt racing
  • US Edition featuring CNC-machined framework from premium 2.0mm Swiss 7075 T6 aluminum material
  • Chassis & backside pod feature pre-drilled centerline holes for maximum weight stability modification making use of HUDY Balancing Tool #107880
  • Chassis includes holes and grooves for composite battery backstops
  • Body posts with fully-adjustable body holders; optional super-fine +1 or +2mm human anatomy backstops available for better still human anatomy height adjustment
  • Chassis design allows either horizontal or straight battery pack placement
  • Chassis design allows to regulate straight battery pack placement
  • Chassis design permits to adjust the front wheelbase



Front suspension system:
  • High-competition, fully-adjustable front suspension with super-clean design of all composite suspension parts
  • EU Edition featuring front reduced & upper hands and steering obstructs produced from difficult material to really make the automobile easier to drive and provide smoother steering
  • US Edition features unique graphite suspension arms that reduces torsional flex of the hands into the corners of very-high traction songs, making the vehicle more reactive and simpler to drive
  • Shims included for adjusting top supply position
  • Precision steering block and front upper ball bones to get more accurate steering
  • Bumpsteer shims for enhanced steering
  • Lower suspension system hands feature smart eccentric aluminum inserts for quick & simple track-width adjustment
  • Optional aluminum 0.5mm and 1.0mm eccentrics for setting track width
  • Ride height adjustment shims for fast, accurate, and hassle-free ride height adjustment for various track conditions. Set of 0.2, 0.4, and 0.6mm ride height adjustment shims are included.
  • fast & easy front caster modification via included clips
  • All composite parts manufactured by XRAY making use of premium self-developed composite mixtures which guarantee ideal flex associated with suspension system parts yet hard sufficient to withstand heavy crashes
  • Reactive caster adjustment (preset 2.5°, 5.0° or 7.5°) via easy-to-change eccentric bushings
  • Ultra-precise wheel axles CNC-machined from premium HUDY Spring Steel™ also hardened and hand ground for precision fitment
  • High-precision, HUDY Spring Steel™ top pivot balls guarantee super-fine movement of front side suspension
  • Composite reduced pivot balls for smooth front suspension movement
  • Lightweight front top 3mm adjustable HUDY Spring Steel™ camber turnbuckles can withstand hefty crashes
  • Quick & simple wheelbase modification by moving the complete front suspension system regarding the framework 2mm front side or back



Steering:
  • Unique adjustable servo mount can accommodate various types of 1/12 servos, and enables modification of servo to chassis centerline
  • Floating servo will not touch chassis, eliminating unwelcome tweak
  • Super-tiny yet robust steering blocks with specially-designed axles prevent axle rotating while tightening the wheel locknuts
  • Pivoting front suspension has super-smooth hardened metal kingpins supported by soft springs. Optional medium, difficult, and extra-hard suspension system springs available.
  • Tiny yet robust servo saver with simple Ackermann adjustment via included shims
  • 4-spring servo saver for exact, smooth steering
  • Specially-designed narrow composite ball joints
  • Adjustable, super-lightweight Swiss 7075 T6 aluminum turnbuckles



Back pod:
  • Compact, ultra-lightweight slim rear pod comprised of high-strength aluminum bulkheads, graphite brace, and strong high-grade 2.5mm graphite plates
  • Unique aluminum bulkheads and top bulkhead clamp are CNC-machined from premium extra-hard Swiss 7075 T6 aluminum, in addition black coated for long life & stylish look
  • Optional eccentric top clamps permits to regulate rear wheelbase
  • Light, small pod pivot ball decreases the extra weight of going components and advances the motion range of a corner pod plate
  • Optimized rear pod link positions
  • Rear pod upper dish includes mounting hole for optional part shock (for different damping faculties)
  • Premium-grade graphite upper deck provides solid accessory for surprise absorber to rear pod
  • Premium graphite back website link brace holds along side it tubes in addition to part springs and human anatomy posts
  • Premium graphite rear link brace enables to mount graphite adjustable battery backstop and features grooves the O-ring which secures the battery
  • Super-easy engine top access
  • Rear pod accommodates all motors
  • Ride height shims for ultra-fine back trip height adjustment
  • Rear differential features high-grade accuracy carbide balls (for spur gear), hardened and precision-ground metal D- shims, and premium carbide 3x8mm axial thrustbearing
  • Ultra-lightweight graphite backside axle
  • Precision-molded spur gear produced from XRAY's exclusive composite product, ensuring real operating, super-quiet procedure, super lightness and robustness for managing powerful motors
  • Aluminum backside hubs machined from lightweight aircraft aluminum, specifically lightened and black-coated for trendy look
  • Lightweight backside wheel mounting screws for paid off rotating weight
  • Aluminum backside left wheel hub with center-balanced clamping mounting system, guarantees safe mounting while eliminating vibration and run-out
  • Easy rear track-width adjustment via included shims
  • Rear body articles are installed towards framework via a wide independently-mounted graphite owner, ensuring human anatomy downforce is precisely used in the chassis
  • Rear pod fat stability can be easily adjusted via shims between motor and bulkhead
  • Straight part springs have more consistent and smoother compression for better out-of corner exiting and paid off traction rolling



Shock:
  • XRAY micro surprise with similar design to its “big brother” counterpart in XRAY’s successful T4 touring car platform
  • Centralized surprise absorber position
  • 4 frontward, 4 rearward shock place options
  • Fully-adjustable shock with hard-anodized aluminum shock body for superior durability, and additionally black-coated for trendy look
  • Fine-threaded surprise body for quick & effortless surprise springtime preload adjustment
  • Tiny, slim surprise membrane provides super-smooth damping traits
  • Super-soft silicone surprise O-ring for smooth procedure, and improved sealing
  • Ultra-finely finished surprise shaft with precise-molded composite shock piston guarantees optimal oil movement and smooth shock absorber action
  • Simple yet smart surprise construction allows for quick & simple shock-length adjustment for downstop
  • Shock place modification via shimming of mounting ball studs
  • Rear pod side balance managed by part tubes which give equalized lateral damping both in instructions while eliminating undesirable rebound
  • Rigid centrally-mounted surprise mount stops tweak, and notably improves lateral stability
  • 1-hole piston for improved damping characteristics
  • Shock length adaptor is roofed to change shock size



Assembly & support:
  • Highest quality composite parts guarantee super-precise fitment, easy assembly, and smooth procedure of most parts
  • Premium 3D full-color Instruction Manual
  • Exclusive Virtual On The Web Setup Sheet database with large number of set-up sheets for competition tracks round the world
  • Premium, unmatched XRAY on line help



Adjustment opportunities:
  • Front Side camber, caster, and toe
  • Front & back wheelbase
  • Front & back track-width
  • Front, center, and back ride height
  • Front springs
  • Central shock absorber length & position
  • Downstops
  • Pod damping
  • Bumpsteer
  • Weight balance
  • Ackermann
  • Front brace stiffness
  • Differential setting
  • Servo place
  • Battery position



Specs:



Measurements

Class:

1/12 electric pan automobile

Width:

Adjustable 167mm +/- 3mm front

Length:

264 mm (varies dependent on rear tires used)

Wheelbase:

201+/- 0.5mm

Weight:

205 g

Ready-to-run fat:

840 g - incl. BL system (varies based on equipment used)

Chassis

Chassis:

EU edition - 2.5mm carbon fibre, CNC machined

US edition - 2.0mm Swiss 7075 T6 aluminum, CNC machined

Body:

Maybe not included, makes use of 1/12 pan automobile type

Drivetrain

Type:

2WD direct drive to rear axle

Rear Axle:

Graphite shaft with ball differential

Main:

Spur / pinion

Bearings:

High-speed ball-bearings (10)

Suspension System

Front Side:

Spring-supported, kingpin-style front suspension system with upper & lower suspension system hands and steering blocks

Backside:

Articulating back engine POD adjustable via pivot-ball links, managed by back surprise absorber

Rear Shock:

Central adjustable oil-filled surprise absorber

Geometry

Ride Height:

Adjustable front side + rear

Wheelbase:

Adjustable

Camber:

Adjustable front

Front Caster (Static):

1–14.5° static adjustable static caster

Front Caster (Reactive):

2.5–7.5° adjustable reactive caster

Track-width:

Adjustable front and rear

Toe:

Adjustable front side

Downstop:

Adjustable rear

Ackermann:

Adjustable with shims

Bumpsteer:

Adjustable with shims

Steering:

Direct linkage between steering servo saver and steering blocks

Balance:

Front/rear fat balance adjustable via battery position

Other

Wheels:

Perhaps not included

Tires:

Maybe not included

Directions:

Full-color instruction manual

Set-up Book:

Printed variation not included. Latest full-color Set-up guide (16 pages) are downloaded from XRAY website. Set-up Book shows previous XRAY models in photographs included within it, however the methodology and set-up concept are exactly the same for several 1/12 pan cars

Packaging:

Carton package with vinyl bags containing components

Furthermore included:

HUDY Diff Grease, Authentication Certificate, parts list & exploded view, decals, natural oils

Perhaps not included:

Motor, batteries, rate controller, tires, body, steering servo, radio equipment, tools
