XRAY X12



2019 All-new Specs
  • All-new EU and US Edition both designed & optimized for specific traction conditions
  • All-new EU Edition is optimized for low-, medium-, and high-traction conditions
  • All-new United States Edition is optimized for high- and very-high traction conditions
  • All-new 2.5mm graphite framework for EU Edition with battery pack backstop grooves
  • All-new 2.0mm Swiss 7075 T6 aluminum framework with battery pack backstop grooves
  • All-new back wheelbase adjustment
  • All-new top clamps with composite bushing for better durability
  • All-new bulkheads make use of brand new upper clamps
  • All-new graphite rear brace with integrated backstop and O-ring battery mount system
  • All-new O-ring for securing the battery
  • All-new adjustable graphite battery backstop with 4 positions
  • All-new longer front graphite bumper owner



General
  • XRAY 1/12 pan-car with authentic 100percent self-developed XRAY parts, designed and manufactured by XRAY in Europe
  • Legendary XRAY premium design, workmanship & material quality and unmatched attention to the best details
  • Simple yet effective and proven design, well thought-out details, unmatched accuracy of most tiny details
  • High-competition design with give attention to ultra-low weight, causing super-lightweight construction
  • Optimized for indoor carpeting racing including outside asphalt rushing



Chassis
  • EU Edition featuring CNC-machined chassis from rigid custom-manufactured 2.5mm high-grade graphite product with specially-designed mixture for carpeting and asphalt racing
  • US Edition featuring CNC-machined chassis from premium 2.0mm Swiss 7075 T6 aluminum material
  • Chassis & rear pod feature pre-drilled centerline holes for maximum fat balance modification making use of HUDY Balancing Tool #107880
  • Chassis includes holes and grooves for composite battery backstops
  • Body articles with fully-adjustable human body holders; optional super-fine +1 or +2mm human body backstops designed for even better human anatomy height adjustment
  • Chassis design permits either horizontal or vertical battery pack placement
  • Chassis design permits to modify straight battery pack placement
  • Chassis design permits to regulate the leading wheelbase



Front suspension:
  • High-competition, fully-adjustable front suspension with super-clean design of most composite suspension system parts
  • EU Edition featuring front reduced & top hands and steering obstructs created from difficult product to really make the automobile simpler to drive and present smoother steering
  • US Edition features unique graphite suspension hands that reduces torsional flex of the hands into the corners of very-high traction tracks, making the car more reactive and better to drive
  • Shims included for adjusting top arm position
  • Precision steering block and front upper ball bones for lots more exact steering
  • Bumpsteer shims for enhanced steering
  • Lower suspension system arms function smart eccentric aluminum inserts for quick & simple track-width adjustment
  • Optional aluminum 0.5mm and 1.0mm eccentrics for establishing track width
  • Ride height adjustment shims for quick, accurate, and hassle-free ride height adjustment for different track conditions. Pair of 0.2, 0.4, and 0.6mm ride height adjustment shims are included.
  • Quick & effortless front side caster adjustment via included clips
  • All composite components manufactured by XRAY using premium self-developed composite mixtures which guarantee perfect flex for the suspension system components yet difficult enough to withstand hefty crashes
  • Reactive caster modification (preset 2.5°, 5.0° or 7.5°) via easy-to-change eccentric bushings
  • Ultra-precise wheel axles CNC-machined from premium HUDY Spring Steel™ furthermore hardened and hand ground for precision fitment
  • High-precision, HUDY Spring Steel™ upper pivot balls make sure super-fine movement of front side suspension
  • Composite lower pivot balls for smooth front suspension movement
  • Lightweight front top 3mm adjustable HUDY Spring Steel™ camber turnbuckles can withstand heavy crashes
  • Quick & simple wheelbase modification by moving the whole front suspension on chassis 2mm front or back



Steering:
  • Unique adjustable servo mount can accommodate various types of 1/12 servos, and allows adjustment of servo to chassis centerline
  • Floating servo cannot touch chassis, eliminating undesired tweak
  • Super-tiny yet robust steering blocks with specially-designed axles prevent axle spinning while tightening the wheel locknuts
  • Pivoting front suspension has super-smooth hardened steel kingpins supported by soft springs. Optional medium, difficult, and extra-hard suspension springs available.
  • Tiny yet robust servo saver with simple Ackermann modification via included shims
  • 4-spring servo saver for precise, smooth steering
  • Specially-designed narrow composite ball joints
  • Adjustable, super-lightweight Swiss 7075 T6 aluminum turnbuckles



Rear pod:
  • Compact, ultra-lightweight narrow backside pod comprised of high-strength aluminum bulkheads, graphite brace, and strong high-grade 2.5mm graphite plates
  • Unique aluminum bulkheads and upper bulkhead clamp are CNC-machined from premium extra-hard Swiss 7075 T6 aluminum, in addition black coated for very long life & trendy look
  • Optional eccentric top clamps allows to regulate rear wheelbase
  • Light, small pod pivot ball decreases the weight of going components and advances the movement array of a corner pod plate
  • Optimized backside pod website link positions
  • Rear pod upper plate includes mounting gap for optional part shock (for different damping traits)
  • Premium-grade graphite upper deck provides solid attachment for shock absorber to rear pod
  • Premium graphite rear link brace holds the medial side pipes as well as side springs and human body posts
  • Premium graphite back website link brace allows to mount graphite adjustable battery backstop and features grooves the O-ring which secures the battery
  • Super-easy motor top access
  • Rear pod accommodates all motors
  • Ride height shims for ultra-fine rear ride height adjustment
  • Rear differential features high-grade precision carbide balls (for spur gear), hardened and precision-ground steel D- shims, and premium carbide 3x8mm axial thrustbearing
  • Ultra-lightweight graphite back axle
  • Precision-molded spur gear created from XRAY's exclusive composite material, ensuring true operating, super-quiet operation, super lightness and robustness for handling effective motors
  • Aluminum rear hubs machined from lightweight aircraft aluminum, specifically lightened and black-coated for trendy look
  • Lightweight rear wheel mounting screws for paid off rotating weight
  • Aluminum rear left wheel hub with center-balanced clamping mounting system, guarantees protected mounting while eliminating vibration and run-out
  • Easy rear track-width modification via included shims
  • Rear human body articles are installed toward framework via an extensive independently-mounted graphite holder, ensuring human body downforce is correctly utilized in the chassis
  • Rear pod fat balance can be simply adjusted via shims between motor and bulkhead
  • Straight side springs do have more consistent and smoother compression for better out-of part leaving and paid down traction rolling



Shock:
  • XRAY micro shock with comparable design to its “big brother” counterpart in XRAY’s successful T4 touring automobile platform
  • Centralized surprise absorber position
  • 4 frontward, 4 rearward shock place choices
  • Fully-adjustable surprise with hard-anodized aluminum surprise body for superior durability, and additionally black-coated for fashionable look
  • Fine-threaded surprise human body for fast & easy shock spring preload adjustment
  • Tiny, thin shock membrane layer gives super-smooth damping traits
  • Super-soft silicone surprise O-ring for smooth operation, and enhanced sealing
  • Ultra-finely finished shock shaft with precise-molded composite surprise piston guarantees optimal oil movement and smooth shock absorber action
  • Simple yet smart surprise construction allows for quick & simple shock-length modification for downstop
  • Shock place modification via shimming of mounting ball studs
  • Rear pod side stability managed by part tubes which give equalized lateral damping in both directions while eliminating undesirable rebound
  • Rigid centrally-mounted shock mount stops tweak, and considerably improves lateral stability
  • 1-hole piston for enhanced damping characteristics
  • Shock length adaptor is included to improve surprise length



Assembly & support:
  • Highest quality composite parts guarantee super-precise fitment, effortless construction, and smooth procedure of most parts
  • Premium 3D full-color Instruction Manual
  • Exclusive Virtual On The Web Setup Sheet database with tens of thousands of set-up sheets for battle songs around the world
  • Premium, unmatched XRAY on line help



Adjustment possibilities:
  • Front camber, caster, and toe
  • Front & backside wheelbase
  • Front & back track-width
  • Front, center, and rear ride height
  • Front springs
  • Central shock absorber size & position
  • Downstops
  • Pod damping
  • Bumpsteer
  • Weight balance
  • Ackermann
  • Front brace stiffness
  • Differential setting
  • Servo position
  • Battery position



Specs:



Proportions

Course:

1/12 electric pan vehicle

Width:

Adjustable 167mm +/- 3mm front

Length:

264 mm (varies depending on back tires utilized)

Wheelbase:

201+/- 0.5mm

Weight:

205 g

Ready-to-run weight:

840 g - incl. BL system (varies dependent on gear utilized)

Framework

Chassis:

EU version - 2.5mm carbon fiber, CNC machined

United States edition - 2.0mm Swiss 7075 T6 aluminum, CNC machined

Body:

Not included, uses 1/12 pan vehicle kind

Drivetrain

Kind:

2WD direct drive to rear axle

Back Axle:

Graphite shaft with ball differential

Primary:

Spur / pinion

Bearings:

High-speed ball-bearings (10)

Suspension System

Front:

Spring-supported, kingpin-style front suspension system with upper & reduced suspension system arms and steering blocks

Rear:

Articulating back motor POD adjustable via pivot-ball links, controlled by back shock absorber

Rear Shock:

Central adjustable oil-filled shock absorber

Geometry

Ride Height:

Adjustable front side + backside

Wheelbase:

Adjustable

Camber:

Adjustable front

Front Caster (Static):

1–14.5° fixed adjustable fixed caster

Front Caster (Reactive):

2.5–7.5° adjustable reactive caster

Track-width:

Adjustable front and rear

Toe:

Adjustable front

Downstop:

Adjustable backside

Ackermann:

Adjustable with shims

Bumpsteer:

Adjustable with shims

Steering:

Direct linkage between steering servo saver and steering blocks

Balance:

Front/rear fat balance adjustable via battery position

Other

Wheels:

Maybe not included

Tires:

Maybe not included

Directions:

Full-color instruction manual

Set-up Book:

Printed variation maybe not included. Latest full-color Set-up Book (16 pages) are installed from XRAY website. Set-up Book shows past XRAY models in photographs contained within it, however the methodology and set-up concept are exactly the same for many 1/12 pan automobiles

Packing:

Carton field with vinyl bags containing parts

In addition included:

HUDY Diff Grease, Authentication Certificate, parts list & exploded view, decals, natural oils

Not included:

Motor, batteries, rate controller, tires, body, steering servo, radio gear, tools
