XRAY 370703 X1 2018 Specs   [XR-370703]

XRAY 370703 X1 2018 Specs
價格:
HKD$3,036.53
牌子:
XRAY
型號:
XR-370703
請輸入姓名和電子郵件地址。當貨品重新上架我們將笫一時間通知閣下.
你或可於 R/C Models - On-Road - Formula Cars
類別中嘗試尋找類似的產品
填寫評論
alt="XRAY 370703 X1 2018 Specs" title="XRAY 370703 X1 2018 Specs"
alt="XRAY 370703 X1 2018 Specs" title="XRAY 370703 X1 2018 Specs"
alt="XRAY 370703 X1 2018 Specs" title="XRAY 370703 X1 2018 Specs"
alt="XRAY 370703 X1 2018 Specs" title="XRAY 370703 X1 2018 Specs"
alt="XRAY 370703 X1 2018 Specs" title="XRAY 370703 X1 2018 Specs"
alt="XRAY 370703 X1 2018 Specs" title="XRAY 370703 X1 2018 Specs"
alt="XRAY 370703 X1 2018 Specs" title="XRAY 370703 X1 2018 Specs"
alt="XRAY 370703 X1 2018 Specs" title="XRAY 370703 X1 2018 Specs"
alt="XRAY 370703 X1 2018 Specs" title="XRAY 370703 X1 2018 Specs"
alt="XRAY 370703 X1 2018 Specs" title="XRAY 370703 X1 2018 Specs"
alt="XRAY 370703 X1 2018 Specs" title="XRAY 370703 X1 2018 Specs"
alt="XRAY 370703 X1 2018 Specs" title="XRAY 370703 X1 2018 Specs"
Dimensions
  • Class: 1/10 formula
  • Width: Adjustable 180mm front, 185mm back (is based on tires used)
  • Lenght: 410 mm
  • Wheelbase: 264 mm
  • Weight: 375 g
  • Ready-to-run weight: 985 g (varies depending on gear utilized)


Chassis
  • Chassis: 2.5 mm carbon dietary fiber, CNC machined
  • Body: XRAY X1 1/10 formula kind


Drivetrain
  • Type: 2WD direct drive to rear axle
  • Rear Axle: metal shaft with ball differential
  • Primary: Spur/pinion
  • Bearings: High-speed ball-bearings (13)


Suspension
  • Front: Spring-supported, kingpin-style front suspension system with composite steering blocks and graphite upper & lower suspension arms
  • back: mainstream back pod, adjustable via pivot-ball links, controlled by side tubes
  • Rear Shock: Central adjustable oil-filled shock absorber


Geometry
  • Ride Height: Adjustable front + rear
  • Camber: Adjustable front
  • Front Caster: 3–12° adjustable caster
  • Track-width: Adjustable front + rear
  • Toe: Adjustable front
  • Downstop: adjustable front + rear
  • Anti-roll club: 1.2 mm front
  • Ackermann: adjustable with servo saver arm and steering block
  • Steering: Direct linkage between steering supply and steering blocks
  • Balance: Front/rear fat balance adjustable via battery pack position


Other
  • Wheels: Not included
  • Tires: Not included
  • Instructions: Comprehensive colour instruction manual
  • Packaging: Carton field with vinyl bags with parts
  • Additionally included: Lexan Formula body & front wing, HUDY Diff Grease, Authentication Certificate, components list & exploded view, surprise oil
  • Not included: Radio system (transmitter and receiver), steering servo, engine, pinion gear, battery pack, rate controller, charger, tires, tires, inserts, high-strength fiber tape, double-sided tape, CA glue, bearing oil, tools
備註 :
由於庫存數量有限, 某些 XRAY 產品可能要特別從製造商訂購, 所需準備時間約為4-6週, 如我們庫存未能提供訂單上的某些產品, 我們將直接為客人從製造商訂購而買家須接受該所需的準備時間。
