XRAY 370704 X1 2019 Specs   [XR-370704]

1/10 DELUXE ELECTRIC FORMULA

• All-new super-narrow framework design is 24mm narrower to eliminate chassis contact with the track while rolling
• All-new redesigned part website link adaptors – machined from graphite – are installed to aluminum really stands to work well with brand new super-narrow chassis
• All-new steering blocks with brand new extra Ackermann position for lots more in-corner steering and nearly 100% Ackermann curve
• All-new surprise adaptor for fast & simple surprise place modifications; brand new frontward position for improved drivability over bumps and enhanced on-power traction
• All-new graphite servo owner allows mounting of the latest shock adaptor
• All-new tweak-free pivot brace for quicker & easier pod dish mounting
• All-new rear website link brace with longer leads for battery part end allows 5mm modification of battery pack position
• All-new battery pack backstop mounting allows battery place adjustment
• Current most useful performing 1/10 formula car: 2x European Champion, 3x ETS Champion, Snowbird Champion, IIC Champion, and lots of nationwide championship titles
• Platform (including just about all components) works with with previous X1 versions
• 2018 variation centered on fine enhancement of tiny details, making the car a complete champion right out of the package

• XRAY 1/10 Formula race automobile with authentic 100% self-developed XRAY components, designed and manufactured parts by XRAY in Europe
• Legendary XRAY premium design, workmanship & product quality and unmatched awareness of the best details
• Simple yet effective and proven design, well thought-out details, unmatched accuracy in all details
• High-competition design with concentrate on ultra-low fat, causing super-lightweight construction
• Optimized for indoor carpeting racing and outside asphalt racing
• Elegant in simplicity & effectiveness, the X1 is scheduled to end up being the brand new standard in 1/10 Formula race

• CNC-machined from custom-manufactured 2.5mm high-grade graphite product with a specially-designed element for carpet race and asphalt racing
• Super-narrow framework front allows for optimum traction while keeping sufficient steering and cornering speed
• Chassis design has optimal stiffness for excellent managing, flexibility for optimum traction, and perfect torsional stability
• Superb managing on either interior or outdoor songs, on carpet or asphalt

• Improved steering response and optimal side-to-side weight transition
• Rear graphite brace holds battery set up, and offers a solid mounting base the optional part shock
• Battery placement are quickly changed from inline to cross-chassis, to offer perfect weight balance according to track conditions; composite battery pack backstops remove battery pack movement
• Cross-chassis battery pack placement has adjustable place up to 5mm too because of the adjustable battery backstop in chassis
• Laydown steering servo orientation for lowest CG at chassis center
• Front center shock mount is put within the absolute framework center for perfect side-to-side weight transfer
• Chassis and back pod feature pre-drilled centerline holes for maximum weight stability adjustment using HUDY Balancing Tool #107880

• Strong, simple, completely adjustable, yet smart and ultra-efficient front suspension
• High-grade graphite lower & upper suspension arms and supply mount plate
• Tiny, strong composite pivot balls for smooth, bind-free operation
• Adjustable front caster via eccentric bushings for front top plate:  3°, 6°, 9°, and 12°
• Adjustable front side camber via eccentric bushings for front top hands:  1.0°, 1.5°, 2.0°, and 2.5°
• Front adjustable anti-roll club with optional full selection of wires for fine tuning
• Adjustable front side upper & reduced roll facilities via included shims
• Adjustable front track-width adjustment via included wheel axle shims

• Independent drifting servo mounting system: selection of separate or fixed position
• Tiny, robust 4-spring servo saver protects the servo from effect harm. Provides accurate steering and consistent managing, while making the car easier to drive
• Pre-drilled framework holes to allow for either a micro or mid-size steering servo
• Centralized servo position for perfect steering faculties
• Centrally-positioned servo saver arm with selectable Ackermann positions
• Servo arm mounting: choice of separate floating or standard mounting
• Adjustable bumpsteer characteristics via included shims
• Steering backstops attached to reduced arms allow modification of optimum steering angle
• Super-tiny yet robust steering blocks with extra new Ackermann positions for more steering, and ultra-precise inner gap for kingpin guarantees wobble-free assembly
• Super-smooth hardened metal kingpins
• Adjustable, lightweight aluminum turnbuckles for front toe adjustment

• Compact, ultra-lightweight rear pod design with composite rear pod links situated nearer to chassis centerline
• Narrow rear pod design offers enhanced steering response and optimal side-to-side fat transition
• CNC-machined pod bulkheads made from premium extra-hard Swiss 7075 T6 aluminum, additionally black colored coated for long life and stylish look
• Rear pod upper dish produced from strong graphite plate could be the base for the central shock, the platform for the part tubes, and it connects the leading framework installation using the rear pod
• Rear wing graphite mount features multiple wing height mounting positions even for better adaptation to various traction conditions
• Smart pod design accommodates all engines, allows for super-easy engine access
• Pod pivot brace features an ultra-small and lightweight pivot ball for smooth movement
• Eccentric composite bushings are included for ultra-fine back ride height adjustment
• Lateral damper part pipes for smoother, more consistent operation
• Linear side springs for consistent and smooth compression for smooth out-of corner exiting, and reduced amount of traction rolling

• Well-proven short surprise from T4 touring automobile platform.
• Interchangeable internal parts, with fixed 1-piece precision pistons which are available with 3 different-diameter holes for damping adjustment: 1.1, 1.2, and 1.3mm with 3 and 4 holes
• CNC-machined Swiss 7075 T6 aluminum shock human anatomy, hard-anodized, with fine outside threading for fast & simple surprise spring preload adjustment
• Super-soft silicone shock O-ring for smooth procedure while preventing oil leakage
• Ultra-finely completed hardened shock shaft
• Self-centering shims contain the shock O-rings, for perfect positioning in the surprise body
• Finely-threaded aluminum surprise reduced cap secures the silicone O-rings and shims within the shock body
• Super-soft silicone membrane, supported by a miniature foam pad, provides proper damping characteristics
• Aluminum surprise spring collar permits fast & easy downstop adjustment
• The C=2.3 linear 3S shock springtime provides the most readily useful stability between traction, security, and steering response; a whole range of optional springs can be obtained for further fine adjustment
• Complete range of springs including modern 3S springs (optional)
• Aluminum modern shocks system for enhanced traction & steering (optional)
• Brand New adaptor enables long shock mounting for improved traction and better driving over bumps

• CNC-machined ultra-precise wheel axles made from premium HUDY Spring Steel™ are also hardened and hand-ground for precision fitment
• Ultra-strong lightweight hollow steel axle for maximum reliability and paid off rotational weight
• Rear differential with high-grade precision carbide balls for spur gear, hardened & precision-ground D-shaped metal shims, and premium carbide axial thrust-bearing
• Precision-molded spur gear made from XRAY's exclusive composite product, guarantees real operating, super-quiet operation, and robustness to be used with powerful motors
• CNC-machined back hubs produced from lightweight aircraft aluminum, especially lightened and black-coated for trendy looks
• Rear left aluminum wheel hub features a center-balanced clamping mounting system, ensuring safe mounting while eliminating vibration and run-out
• Full set high-speed, blue-sealed, metal ball-bearings used through the entire drivetrain and steering to make sure maximum efficiency. All bearings are degreased and oiled with AeroShell® Fluid 12 for maximum smoothness and long life
• Easy back track-width modification via included shims

• Robust human anatomy articles mounted on the solid platform on aluminum really stands, featuring fully-adjustable human body holders
• Multi-part front spoiler is made of composite bumper and Lexan™ downforce spoiler
• Composite front framework bumper is quite rigid yet versatile to give superior protection
• Lightweight Lexan™ front side spoilers – selection of low or high downforce spoilers for distinction track conditions
• High-efficiency, high-strength, adjustable-downforce back wing with adjustable mounting height position
• High-performance, low-profile aerodynamic X1 human body produced from top-notch premium Lexan™ material for optimum flexibility in most track conditions. Rear air networks direct airflow onto rear wing. Body edges and cockpit edges are because flat as you possibly can to direct airflow around the human body for maximum stability. On the rooftop, two movement networks are incorporated for proper venting. A helmet guarantees the human body is legal for races where a pilot figure helmet is required.

• Highest quality of composite components ensures super-precise fitment, easy installation, and smooth procedure of most parts
• Premium 3D full-color Instruction Manual
• Exclusive Virtual On The Web Set-up Sheet database with large number of set-up sheets for race tracks round the world
• Premium, unmatched XRAY online support

• Front camber, caster, and toe
• Front & backside track-width
• Front, center, and back ride height
• Front springs
• Front anti-roll bar
• Fully-adjustable rear surprise absorber
• Downstops
• Side damper pipes for lateral pod damping
• Chassis tweak
• Ackermann
• Bump steer
• Differential settings
• Battery position
• Front wing downforce
• Rear wing downforce
• Steering system
• Servo mount system
